3.6V 35Ah Lithium Semi Solid State Battery for UAV Drone Robot

Rated Capacity

35Ah (0.33C)

Nominal Voltage

3.60V

AC Internal Resistance

≤1.3mΩ (50%SOC)

Charging Voltage

4.20V

Cut-off Voltage

2.5V

Standard Charging

Charge at 0.33C (11.6A) constant current (CC) to 4.20V, then constant voltage (CV) charging until the cut-off current of 0.02C (0.70A)

Maximum Charging Current

1C (35A)

Standard Discharging

Discharge at 0.33C (11.6A) constant current (CC) to 2.5V

Multi-rate Discharging

Discharge at 3C (105.0A) constant current (CC) to 2.5V

High Multi-rate Discharging

5C (175A) (Sustainable discharge for 60s at ≥50%SOC)

Ultra-high Multi-rate Discharging

7C (245A) (Sustainable discharge for 10s at ≥50%SOC)

Cycle Life

1.0C/3C normal temperature cycle ≥ 800 times
0.5C/1C normal temperature cycle ≥ 1000 times

Operating Temperature

Charging: 0℃~45℃
Discharging: -20℃~55℃

Storage Temperature

Short-term storage (1 month): -20℃~45℃
Long-term storage (6 months): -10℃~35℃

Storage Humidity

Short-term storage (1 month): RH: ≤90%
Long-term storage (6 months): RH: ≤70%

Energy Density

Gravimetric energy density: 320±10Wh/kg (0.33C)
Volumetric energy density: ≥670Wh/L (0.33C, thickness in delivery state)

Weight

395±10g
